Application Scenarios
Household Gas Appliance Connection
For connecting gas stoves, wall-hung boilers,and gas water heaters, ensuring safe gas delivery in kitchens and bathrooms.
Commercial Catering Scenarios
Suitable for commercial cooking equipment in restaurants and canteens,with excellent wear and aging resistance to meet high-frequency usage demands.
Industrial Low-Pressure Gas Systems
Used in small industrial burners, drying equipment, and other low-pressure gas systems to provide stable gas supply.
Brazil Market Adaptation
Compliant with Brazilian gas safety standards,adapted to local climate and pressure fluctuations, and compatible with mainstream gas interface specifications in Brazil.
| Code | DN | Length cm | Size |
| KL 220025 | 12 | 30-60 | M1/2"-F1/2"WATER |
| KL 220026 | 12 | 30-60 | M1/2"-F1"WATER |
| KL 220027 | 15 | 30-60 | M1/2"-F1/2"GAS VALVE |
| Parameters | Specifications |
| Product Structure | Inner:SUS Corrugated Pipe; Outer: Stainless steel wire braided (Polybutylene Terephthalate) Coating; Fittings: Brass/Nickel-Plated Brass |
| Working Pressure | 0.1-0.6 MPa |
| Burst Pressure | >3.0 MPa |
| Applicable Medium | Natural Gas, Liquefied Petroleum Gas (LPG), Artificial Gas |
| Working Temperature | -30°C~+120°C |
| Fitting Specification | 1/2" BSP (Mainstream in Brazil), 3/4" BSP optional |
| Certification | INMETRO (Mandatory in Brazil), CE |
| Aging Resistance Life | >10 Years |
| Minimum Bending Radius | >4 x Pipe Diameter |
| Code | DN | Length cm | Size |
| KL 220028 | 12 | 30-60 | M1/2"-F1/2"WATER |
| KL 220029 | 12 | 30-60 | M1/2"-F1/1/2"WATER |
| KL 220030 | 15 | 30-60 | M1/2"-F1/2"GAS VALVE |
